THE RADEKER & GARRELS ORGAN OF THE MAGNUSKERK ANLOO (NL) VERSION 2
Pictures/Videos
Description
The organ of the Magnuskerk (Anloo, NL) was built in 1717-1719 by Johannes Radeker and Rudolph Garrels, two co-workers of Arp Schnitger. It originally had 2 manuals with 17 stops and an attached pedal. A crest board attached in front of the organ displays the crests of the wealthy families that financed the organ.
In 1944-1950 the organ was modified by Mense Ruiter. From 1990 to 2002 it was restored/reconstructed by Henk van Eeken (Herwijnen, NL). The goal was the best possible reconstruction of the original state. As 1995 a workshop fire lead to the loss of a large portion of the pipe work, the partial reconstruction of the organ became necessary.
In 2002 the restored/reconstructed organ including an added four stop pedal was recommissioned. Through the restoration the original sound of the instrument could be regained to a great extent.
With regard to the quality of the restoration/reconstruction result, Henk van Eeken's cooperation with GOArt (Göteborg Organ Art Center) was of special importance. GOArt is an international research center for organ history, organ building, artistic education and performance practice of the University of Gothenburg in Sweden. Through scientific research it was possible to reconstruct historical organ building procedures and techniques.
The results of this work were applied to the restoration/reconstruction of the Anloo organ. That way it became possible for the first time to faithfully manufacture new organ pipes by reconstructing the original processes and techniques from 1717. For example, the organ metal was cast on sand and subsequently scraped down manually to the correct thickness.
With a high degree of certainty the organ has also regained its original temperament and pitch from 1718 (following Arp Schnitger, St. Cosmae, Stade).
Further information about the Anloo organ and the sample set (version 2) can be found [here].
Also, we recommend Henk van Eekens's fascinating documentary 'The search for an organ sound as good as old' on YouTube (Dutch + English subtitles):
- [part 1/2]
- [part 2/2]
Here are a few sound demos (more will be uploaded to Contrebombarde soon):
- [Scheidt, Samuel: Variationen 'Ach du feiner Reuter' (using both IRs)
- [Kerkhoven, Abraham van den: Versi Primi toni (using the main IR only)
- [Buxtehude, Dietrich: Fuge in C BuxWV 174 (using both IRs)
- [Pachelbel, Johann: Fughetta 'Ein feste Burg ist unser Gott' (comparison: Both IRs and main IR only)
Specification
| Manuael |
|
|
| |
|
|
| Quintadena |
16 voet |
|
| Principael |
8 voet |
|
| Quintadena*1 |
8 voet |
|
| Roerpijp |
8 voet |
|
| Octav |
4 voet |
|
| Spitspijp |
4 voet |
|
| Quint |
3 voet |
|
| Super Octav |
2 voet |
|
| Woudfloit*1 |
2 voet |
|
| Sexquialter |
2 sterk |
|
| Mixtuir |
4-5-6 sterk |
|
| Trompet |
8 voet |
|
| Vox Humana B/D*2 |
8 voet |
|
| |
|
|
| |
|
|
|
| Borstpositiff |
|
|
| |
|
|
| Gedackt |
8 voet |
|
| Floit |
4 voet |
|
| Nasard*1 |
3 voet |
|
| Octav |
2 voet |
|
| Sijfloit |
1 1/2 foet |
|
| Scherp |
3 sterk |
|
| Dulciaen |
8 voet |
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
|
| Pedael (Henk van Eeken, 2002) |
| |
|
|
| Bardon |
16 voet |
|
| Octav |
8 voet |
|
| Gedackt*1 |
8 voet |
|
| Octav*1 |
4 voet |
|
| Basuin |
16 voet |
|
| Trompet*1 |
8 voet |
|
| Cornet |
4 foet |
|
| |
|
|
| Tremulant (MA) |
|
|
| Tremulant (BP) |
|
|
| Tremulant (PD) |
|
|
| |
|
|
| Koppeling BP-MA |
|
|
| Koppeling MA-PD |
|
|
| Koppeling BP-PD |
|
|
|
|
|
|
|
| *1
Extension stops |
| *2
Split, coupleable |
|
Tuning : St. Cosmae, Stade (modified meantone), f(a')=469 Hz |
About this virtual organ
Recordings have been made using reference quality equipment.
Version 2 is reprocessed in double precision (64 bit) using our new high quality VPOLab© system based on 17 years of experience in digital signal processing algorithms research and development.
Highlights of this virtual organ
- A well-known magnificent baroque organ by Johannes Radeker and Rudolph Garrels
- Size: Two manuals, pedal, 28 stops (21 original + 6 extension stops)
- Anloo Version 2 is semi-dry (no reverb). It is created for use with IR convolution reverb.
Two high quality true stereo IRs of the Magnuskerk in HW5 format (and standard true stereo IR format for HW4 and HW5 Basic users) included
- Improved sound: Samples have been reprocessed with our new VPOLab© system
- High quality voicing: Organ and especially extension stop voicing was not done using Hauptwerk voicing features
but our high quality VPOLab© system.
- Manuals: extended from 49 to 56 keys, Pedal: extended from 25 to 30 keys
- Sample resolution: Stereo, 32bit/48kHz
- Improved Tremulant: Comes with a separate tremulant waveform for each pipe, created using tremulant samples and our new TremulantTemplate© 2.0 algorithm
- Action noises (keys, stops etc.) and blower noise (can be switched on/off) included
- New user interface: Version 2 comes with portrait and landscape screens for practically all console setups,
including separate screens for original and extended functionality.
- Comes with the 6 temperaments suggested for Anloo in the book Opus Magnum In De Magnuskerk
Graphical User Interface
Requirements
- Hauptwerk versions: 4,5,6,7
Latest version 2.0
